Customizable Movable Partition Wall with 68CM Thickness and 800N Sealing Power Operable Wall System

Customizable Movable Partition Wall with 68CM Thickness and 800N Sealing Power Operable Wall System

نام تجاری: AE
شماره مدل: AE65
مقدار تولیدی: 10 متر مربع
قیمت: USD 79-108 per square meter
شرایط پرداخت: T/T، L/C، وسترن یونیون
توانایی عرضه: 1000 متر مربع در ماه
اطلاعات دقیق
محل منبع:
گوانگدونگ، چین
گواهی:
ISO9001 SGS CANS
سری:
دیوار پارتیشن متحرک AE65
گزینه پایان:
مواد عرضه شده توسط مشتری
برنامه:
رستوران، سالن اجتماعات
ضخامت:
68 سانتی متر
رتبه بندی STC:
42-56dB
ابعاد:
سفارشی سازی (ارتفاع: تا 4.5M، عرض هر پانل: تا 1.2M)
نام:
دیوار جداکننده متحرک
جزئیات بسته بندی:
لایه فوم و مقوا سخت با تخته سه لا یا پالت فولادی
برجسته کردن:

68CM Thickness Movable Partition Wall,800N Sealing Power Operable Wall System,40N/m Magnetic Attraction Room Divider

,

800N Sealing Power Operable Wall System

,

40N/m Magnetic Attraction Room Divider

توضیحات محصول
Customizable Movable Partition Wall Office Operable Wall Systems

AE operable partitions are a series of panels suspended from tracks with high quality, functionality and variability for room-dividing and multifunctional layout configuration.

Key Features
  • German Partition Technology Global Professional Space Solutions
  • Highly competitive prices
  • Good quality control
  • Smooth communication
  • State-of-art technology products
  • Effective OEM&ODM service
Roller Options & Features
  • Dupont POM roller
  • 304 stainless steel heavy duty roller with safety device & CNC machining
  • Unique and patented wheel surface and shape for easy operation
Panel Options & Features
  • Thickness: 68mm, 89mm & 105mm options
  • Wide variety of acoustical and decorative finishes available
  • 6061-T6 profile with Q235 steel frame for superior durability
  • Top & bottom jack lifting mechanism seal with 800N power
  • Magnetic seal in concave & convex profile with 40N/m magnetic attraction
Technical Specifications
Series Element Thickness (mm) Element Width (mm)* Clear Height (mm)* Construction Panel Fixing Element Interconnection
AE65 68 600/1,250 2,000/4,500 Aluminium-steel Freely oscillating Aluminium profile with magnetic strip and sealing lips
AE85 89 600/1,250 2,000/5,500 Aluminium-steel Freely oscillating Aluminium profile with magnetic strip and sealing lips
AE100 105 600/1,250 2,000/18,000 Aluminium-steel Freely oscillating Aluminium profile with magnetic strip and sealing lips
Technical Details
  • Weighted sound reduction value: 52/56 dB (Rw) per GB/T19889.3-2005
  • Positive and frictional locking of vertical element connections
  • Convex-concave profile form with magnetic strip attraction force of 40 N/m
* Larger widths possible on application. Provisional details regarding element heights/widths require consultation with Design Department.
